Hollow Screw Jack

JE-301

Thread: 4TPI
Tube OD: 32, 34, 38 mm
Length in mm: 300, 500, 600, 800, 1000
Plate Size: 150*150*5, 150*150*6mm
Jack Nut: Casted and Forged

Solid Screw Jack

JE-302

Thread: 4TPI
Tube OD: 32, 34, 38 mm
Length in mm: 300, 500, 600, 800, 1000
Plate Size: 150*150*5mm
Jack Nut: Casted and Forged

Hollow Screw Jack

JE-303

Thread: 4TPI
Tube OD: 32, 34, 38 mm
Length in mm: 300, 500, 600, 800, 1000
Plate Size: 150*150*5, 150*150*6mm
Jack Nut: Casted and Forged

Hollow Screw Jack

JE-304

Thread: 4TPI
Tube OD: 32, 34, 38 mm
Length in mm: 300, 500, 600, 800, 1000
Plate Size: 150*100*75*5, 115*100*50*5mm
Jack Nut: Casted and Forged

Solid Screw Jack

JE-305

Thread: 4TPI
Tube OD: 32, 34, 38 mm
Length in mm: 300, 500, 600, 800, 1000
Plate Size: 150*150*5mm
Jack Nut: Casted and Forged

Swivel Screw Jack

JE-306

Thread: 4TPI
Tube OD: 32, 34, 38 mm
Length in mm: 300, 500, 600, 800, 1000
Jack Nut: Casted and Forged

Adjustable Base Jack (Flower Plate)

JE-307

Thread: 38x4
Plate Size: 150×150×5/6 mm
Length in mm: 300, 500, 600, 800, 1000
Jack Nut: Casted and Forged
